Overview

• IntroducedDecember 2019
• DiscontinuedJun 2023
• Model IdentifierMacPro7,1
• Model NumberA1991
• Other Model NumbersA2304
• EMC3203, 3413
• Weight/Dimensions

  • 18 kg, 52.9 H x 21.8 cm W x 45 D cm (Tower)
  • 17.6 kg, 22.02 H x 48.2 W x 53.95 D cm (Rack)
  • 39.7 lbs, 20.8 H x 8.58 W x 17.7 D inch (Tower)
  • 38.8 lbs, 8.67 H x 18.98 W x 21.24 D inch (Rack)

Chip

Apple Intel Xeon W-3223, W-3235, W-3245, W-3265M, W-3275M ('Cascade Lake') chip

• Processor NameIntel Xeon W-3223, W-3235, W-3245, W-3265M, W-3275M ('Cascade Lake')
• Processor Speed3.5, 3.3, 3.2, 2.7 or 2.5 GHz
• # of Cores8, 12, 16, 24, 28
• # of Threads16, 24, 32, 48, 56
• Architecture64-Bit
• Manufacturing Process14 nm

Graphics

• Graphics ChipAMD Radeon Pro 580X, W5500X, W5700X, W6800X, W6900X, W6800X Duo, Vega II, Vega II Duo
• Graphics Memory

  • 8 GB GDDR5 (580X, W5500X)
  • 16 GB GDDR6 (W5700X)
  • 32 GB GDDR6 (W6800X, W6900X)
  • 64 GB GDDR6 (W6800X Duo (32 GB per GPU))
  • 32 GB HBM2 (Vega II)
  • 64 GB HBM2 (Vega II Duo (32 GB per GPU))

Memory

• Maximum Memory1.5 TB
• Supported RAM2666/2933 MHz DDR4 ECC R/LRDIMM
• # of Slots12

Storage

• SSD256 GB, 1, 2, 4 or 8 TB

Connections and Expansion

• Wi-Fi802.11ac (Wi-Fi 5)
• Bluetooth5.0
• Ethernet2 - 10 GBit/s
• USB3 - 5 GBit/s (2 - Apple I/O Card, 1 - internal)
• Thunderbolt4 - Thunderbolt 3 (40 GBit/s) (2 - Apple I/O Card, 2 - internal)
• Display1 - HDMI 2.0, Thunderbolt 3
• Audio Out1 - 3.5mm jack, 1 - Built-in Speaker
• PCIe Slots4 - x16 3.0, 3 - x8 3.0, 1 - x4 3.0

Software

• Original OSmacOS 10.15.2 (Catalina)
• Maximum OSLatest release of macOS
